Corbin Russwin
-
-
-
Corbin Russwin ED4200 Exit Device
Corbin Russwin ED4200 Narrow Stile Exit Device
This device is designed for use with a narrow framed glass door, and is recommend for use in high traffic, abusive areas.Device
non-handed.
Trim handed.
Easily field cut to size.
Standard: 36" bar fits 30"- 36"
914mm) door.
Stile
Minimum width 2" (51mm).Replacement parts are also available
ED4200- -
Corbin Russwin ED5400 Exit Device
Corbin Russwin ED5400 Exit Device
Handing
Device is handed but easily field reversible.
Lever trim is handed.
Bar Length
Easily field cut to size.
Standard: 36" (914mm) bar fits 30"- 36" door.
Door Thickness
1-3/4" (44mm) standard.
Stile
Minimum width 4-1/2" (114mm).
Door Height
Standard top rod for 7' door.Replacement parts are also available
ED5400 -
Corbin Russwin ED4200 Active Head
Corbin Russwin ED4200 Active Head
Used on the Corbin Russwin ED4000 Rim Devices, for non fire rated doors. A non fire rated door is a door were you can use your allen wrench to dog, or lock, the door in the open position during business hours.
Corbin Russwin part # 650F37-8
G650F37 -
Corbin Russwin ED5200 Active Head
Corbin Russwin ED5200 Active Head
Used on the Corbin Russwin ED5000 Rim Devices, for non fire rated doors. For fire rated doors, order the G650F36-8. A non fire rated door is a door were you can use your allen wrench to dog, or lock, the door in the open position during business hours.
Corbin Russwin part # 650F35-8
G650F35-8 -
Corbin Russwin Adjusting Nut
Corbin Russwin Adjusting Nut 483F35-8
This Corbin Russwin Adjusting Nut is used on the Corbin Russwin Mortise Lever Locks. It threads into the end of the spindle. 2-3/8" overall length, 9/16" thread length, 1-15/16" bolt length. The threads are 1/4-28.
Corbin Russwin part # 483F35-8
G483F35 -
Corbin Russwin ED5200A Active Head
Corbin Russwin ED5200A Active Head
Used on the Corbin Russwin ED5000 Rim Devices, for fire rated doors. For non fire rated doors, order the G650F35-8. A fire rated door is a door were you can NOT use your allen wrench to dog, or lock, the door in the open position during business hours.
Corbin Russwin part # 650F36-8
G650F36-8 -
Corbin 100/110/120 Door Closer
The Russwin 100, 110 and 120 in no longer available. They have been replaced by the DC6210, which has the same hole spacings and arm. You will not have to redrill or modify your door to make the DC6210 work in place of your existing 100, 110 or 120 door closers. The DC6210 has a little bit larger body due to the increased functionality of this closer. This new closer will meet all the ADA requirements.
Uses the same mounting bracket as the 100, and 2800 series.
Older models may have SL72 or MS93 cast on the cylinders. You may also find Clarksdale, MS cast on the cylinder also.
DC6210b -
Corbin Russwin DC3210 Door Closer
Corbin Russwin DC3210 Door Closer
The mid-priced, cost-effective choice for high-traffic situations. Corbin Russwin DC3000 Series Door Closers fulfill security and life safety requirements by ensuring reliable latching for access control and fire code compliance, along with ease of operation and precise adjustability for barrier-free code compliance. Ideal for virtually all door openings and draft conditions in both new construction and renovations.
Fits on the same bracket as the 100, 110, 120, 2800, 2810 and 2820 Corbin Russwin Door Closers
Idea for interior doors.
DC3210-
