Von Duprin 98/99 Maintenance Kit
The Von Duprin 98/99 Maintenance Kit includes all the parts and pieces you need to keep your 98 or 99 device running properly for years. If you are interested we can email a list of the parts.
Von Duprin part # 050046
Details
The Von Duprin 98/99 Maintenance Kit includes all the parts and pieces you need to keep your 98 or 99 device running properly for years. If you are interested we can email a list of the parts.
Von Duprin part # 050046
Here is a list of the Contents:
|
Quantity |
Product name |
|
2 |
425 SNB PKG-2 US32D |
|
2 |
325 SNB PKG-2 US32D |
|
4 |
IMPACT RESIST END CAP BRKT PKG |
|
4 |
98/9927 ROD GUIDE PKG US32D |
|
2 |
SA DAMPER ASSY |
|
1 |
33/35/98/99 E/CAP SCREW PKG |
|
1 |
VON DUPRIN MAINT. KIT MANUAL |
|
12 |
264/299F/499F STRIKE SHIM |
|
20 |
8-32 1/4" UFPH MS STL CZNC |
|
12 |
10-32 1/4" UFPH MS SS NYL |
|
12 |
10-24 X 3/4 FPHMS - STL BO |
|
6 |
WAVE SPRING WASHER SS, .440 ID X .618 OD X .008 THICK, .440 |
|
12 |
10-24 3/4" PPHMS STL CZNC |
|
12 |
ROLL PIN SPIROL YZNC STL .1/8 |
|
24 |
10-24 1" PPH MS TYP 2A STL YZN |
|
12 |
#10 EXT TOOTH LOCK WASHER YZNC |
|
12 |
10-24 X 1 3/8 PPHMS 2A - STEEL |
|
25 |
TRUARC RET. RING T5304-18 STL |
|
12 |
10-24 X 3/4 UFPHMS 2A - STEEL |
|
50 |
8-18 3/8" UFPHMS TYP 25 STL CZ |
|
12 |
RET RING #5160-42 TRUARC STL |
|
6 |
1/4-20 5/8" SOC SET STL BO |
|
12 |
1/4-20 3/4" UFPH MS SS |
|
50 |
12-14 1/2" HEX WSHR HD TYP AB |
|
20 |
10-12 X 10-24 X 1 PTHCS - S.S. |
|
10 |
3347A/9947 RATCHET LEVER SPRIN |
|
10 |
BOLT RETURN SPRING YZNC |
|
4 |
CYLINDER RETAINING CUP-210/990 |
|
4 |
ROD EXTENSION CONNECTOR |
|
4 |
EXT ROD DRILL TEMP.-2227/9927 |
|
10 |
9927 AUX. BOLT SPRING YZNC |
|
12 |
299 STRIKE SHIM |
|
4 |
299 STRIKE PLATE |
|
12 |
NL DRIVE SCREW-99 DEVICE - STL |
|
6 |
33/99 ANTI-RATTLE SPRING |
|
1 |
TACKLE BOX |
|
12 |
3347A/9947 COMPRESSION SPRING |
|
30 |
TAILPIECE GUIDE |
|
12 |
992 HEX STUD YZNC |
|
2 |
HEX DOGGING SHAFT YZNC |
|
2 |
DOGGING SPRING BO-WAXED |
|
2 |
DOGGING ADAPTOR SPRING |
|
2 |
CD ACTUATOR YZNC |
|
24 |
992 LIFT SPRING |
|
25 |
SHEAR PIN BD |
|
12 |
994 HEX STUD YZNC |
|
2 |
CD DOGGING PLUG YZNC |
|
20 |
PUSHBAR GUIDE |
|
4 |
MECHANISM END CAP BRKT YZNC |
|
12 |
WS SLIC-PIN |
More Information
| Part # | G050046 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Availability | 1 Week Lead Time | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Manufacturer | Von Duprin Exit Devices | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Short Description | The Von Duprin 98/99 Maintenance Kit includes all the parts and pieces you need to keep your 98 or 99 device running properly for years. If you are interested we can email a list of the parts. Von Duprin part # 050046 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Description | The Von Duprin 98/99 Maintenance Kit includes all the parts and pieces you need to keep your 98 or 99 device running properly for years. If you are interested we can email a list of the parts. Von Duprin part # 050046 Here is a list of the Contents:
|
